About this snippet

Create an authentic sonar experience with an interactive radar scanner animation. We utilized HTML5 Canvas to safely render a sweeping radar arm and dynamically fading blips to locate targets.

Size
3.6 KB
Uses
HTML, CSS, JavaScript
Loads
Nothing external
Views
470
<div class="radar-board">
  <div class="radar-frame">
    <canvas id="radar-canvas"></canvas>
    <div class="radar-overlay"></div>
  </div>
  <h3 class="radar-text">Scanning Sector...</h3>
</div>
*, *::before, *::after {
  box-sizing: border-box;
}

body {
  font-family: system-ui, "Segoe UI", Roboto, Helvetica, Arial, sans-serif, "Apple Color Emoji", "Segoe UI Emoji", "Segoe UI Symbol";
  margin: 0;
  background: #020617;
  display: flex;
  justify-content: center;
  align-items: center;
  min-height: 100vh;
}

.radar-board {
  display: flex;
  flex-direction: column;
  align-items: center;
  gap: 30px;
}

.radar-frame {
  position: relative;
  width: 300px;
  height: 300px;
  border-radius: 50%;
  background: #0f172a;
  border: 4px solid #1e293b;
  box-shadow: 0 0 50px rgba(16, 185, 129, 0.2);
  overflow: hidden;
}

#radar-canvas {
  position: absolute;
  top: 0;
  left: 0;
  width: 100%;
  height: 100%;
  z-index: 1;
}

.radar-overlay {
  position: absolute;
  top: 0;
  left: 0;
  width: 100%;
  height: 100%;
  border-radius: 50%;
  background:
    radial-gradient(circle, transparent 20%, rgba(16, 185, 129, 0.1) 80%),
    linear-gradient(90deg, transparent 49.5%, rgba(16, 185, 129, 0.3) 49.5%, rgba(16, 185, 129, 0.3) 50.5%, transparent 50.5%),
    linear-gradient(0deg, transparent 49.5%, rgba(16, 185, 129, 0.3) 49.5%, rgba(16, 185, 129, 0.3) 50.5%, transparent 50.5%);
  z-index: 2;
  pointer-events: none;
}

.radar-text {
  color: #10b981;
  margin: 0;
  letter-spacing: 4px;
  text-transform: uppercase;
  font-weight: 600;
  animation: pulse-text 2s infinite alternate;
}

@keyframes pulse-text {
  0% { opacity: 0.5; }
  100% { opacity: 1; text-shadow: 0 0 10px #10b981; }
}
const canvas = document.getElementById("radar-canvas");
const ctx = canvas.getContext("2d");

const size = 300;
canvas.width = size;
canvas.height = size;

let angle = 0;
const blips = new Array();

function spawnBlip() {
  const blip = new Object();
  const distance = Math.random() * 100 + 20;
  const blipAngle = Math.random() * Math.PI * 2;

  blip.x = (size / 2) + Math.cos(blipAngle) * distance;
  blip.y = (size / 2) + Math.sin(blipAngle) * distance;
  blip.alpha = 1;
  blips.push(blip);
}

/* Spawn a blip randomly every 2 seconds safely */
setInterval(spawnBlip, 2000);

function drawRadar() {
  /* Create trailing effect */
  ctx.fillStyle = "rgba(15, 23, 42, 0.1)";
  ctx.fillRect(0, 0, size, size);

  const cx = size / 2;
  const cy = size / 2;

  /* Draw Sweeping Beam */
  ctx.save();
  ctx.translate(cx, cy);
  ctx.rotate(angle);

  const gradient = ctx.createLinearGradient(0, 0, 150, 0);
  gradient.addColorStop(0, "rgba(16, 185, 129, 0.8)");
  gradient.addColorStop(1, "rgba(16, 185, 129, 0)");

  ctx.beginPath();
  ctx.moveTo(0, 0);
  ctx.arc(0, 0, 150, 0, 0.2);
  ctx.closePath();
  ctx.fillStyle = gradient;
  ctx.fill();

  /* Solid Leading Line */
  ctx.beginPath();
  ctx.moveTo(0, 0);
  ctx.lineTo(150, 0);
  ctx.strokeStyle = "#10b981";
  ctx.lineWidth = 2;
  ctx.stroke();

  ctx.restore();

  /* Draw Blips */
  for (let i = 0; i < blips.length; i++) {
    const b = blips.at(i);
    if (b.alpha > 0) {
      ctx.beginPath();
      ctx.arc(b.x, b.y, 4, 0, Math.PI * 2);
      ctx.fillStyle = "rgba(16, 185, 129, " + b.alpha + ")";
      ctx.shadowBlur = 10;
      ctx.shadowColor = "#10b981";
      ctx.fill();
      ctx.shadowBlur = 0; /* Reset */

      b.alpha -= 0.005; /* Fade out slowly */
    }
  }

  /* Clean array cleanly */
  while (blips.length > 0 && blips.at(0).alpha <= 0) {
    blips.shift();
  }

  angle -= 0.03;
  window.requestAnimationFrame(drawRadar);
}

drawRadar();
