About this snippet

Present mapping data beautifully with an interactive 3D paper fold UI. Clicking the card unrolls the layout gracefully using nested rotation transforms, recreating real physical origami.

Size
3.0 KB
Uses
HTML, CSS, JavaScript
Loads
placehold.co
Views
416
<div class="fold-wrapper" id="fold-wrapper">

  <!-- Top Panel (Remains static) -->
  <div class="fold-panel panel-top">
    <h3>Headquarters</h3>
    <p>San Francisco, CA</p>
    <button class="expand-btn" id="expand-btn">View Details ↓</button>
  </div>

  <!-- Middle Panel (Hinges from the Top) -->
  <div class="fold-panel panel-mid">
    <div class="mid-content">
      <img src="https://placehold.co/300x120/1e293b/38bdf8?text=Map+View" alt="Map" class="map-img">
    </div>

    <!-- Bottom Panel (Hinges from the Middle) -->
    <div class="fold-panel panel-bottom">
      <div class="bottom-content">
        <p>123 Innovation Drive<br>Suite 400<br>Contact: (555) 123-4567</p>
      </div>
    </div>
  </div>

</div>
*, *::before, *::after {
  box-sizing: border-box;
}

body {
  font-family: system-ui, "Segoe UI", Roboto, Helvetica, Arial, sans-serif, "Apple Color Emoji", "Segoe UI Emoji", "Segoe UI Symbol";
  margin: 0;
  background: #f1f5f9;
  display: flex;
  justify-content: center;
  align-items: center;
  min-height: 100vh;
}

.fold-wrapper {
  perspective: 1200px;
  width: 300px;
  cursor: pointer;
}

.fold-panel {
  width: 100%;
  background: #ffffff;
  transform-style: preserve-3d;
}

.panel-top {
  position: relative;
  z-index: 3;
  padding: 30px 20px;
  border-radius: 16px;
  box-shadow: 0 10px 30px rgba(0, 0, 0, 0.1);
  text-align: center;
}

.panel-top h3 {
  margin: 0 0 5px 0;
  color: #0f172a;
}

.panel-top p {
  margin: 0 0 20px 0;
  color: #64748b;
}

.expand-btn {
  background: #f1f5f9;
  border: none;
  padding: 8px 16px;
  border-radius: 20px;
  font-weight: 600;
  color: #3b82f6;
  cursor: pointer;
}

.panel-mid {
  position: relative;
  transform-origin: top center;
  transform: rotateX(-110deg);
  transition: transform 0.6s cubic-bezier(0.34, 1.56, 0.64, 1);
  /* Make the back invisible cleanly */
  backface-visibility: hidden;
  background: #f8fafc;
}

.mid-content {
  padding: 10px;
  border-left: 1px solid #e2e8f0;
  border-right: 1px solid #e2e8f0;
}

.map-img {
  width: 100%;
  border-radius: 8px;
  display: block;
}

.panel-bottom {
  position: absolute;
  top: 100%;
  left: 0;
  transform-origin: top center;
  transform: rotateX(100deg);
  transition: transform 0.6s cubic-bezier(0.34, 1.56, 0.64, 1);
  backface-visibility: hidden;
  border-radius: 0 0 16px 16px;
  box-shadow: 0 20px 30px rgba(0, 0, 0, 0.15);
  border: 1px solid #e2e8f0;
  border-top: none;
}

.bottom-content {
  padding: 20px;
  color: #334155;
  line-height: 1.6;
  text-align: center;
  font-size: 0.95rem;
}

/* Safely apply opened states via parent class */
.fold-wrapper.is-open .panel-mid {
  transform: rotateX(0deg);
}

.fold-wrapper.is-open .panel-bottom {
  transform: rotateX(0deg);
}
const wrapper = document.getElementById("fold-wrapper");

wrapper.addEventListener("click", function() {
  wrapper.classList.toggle("is-open");

  const btn = document.getElementById("expand-btn");
  if (wrapper.classList.contains("is-open")) {
    btn.innerText = "Close ↑";
  } else {
    btn.innerText = "View Details ↓";
  }
});
